BS6724 LSZH Sheath armored cable

Description

    BS 6724 cables are utilized for power and control circuits. The incorporation of a heavy galvanized steel wire armor (GSWA) endows these cables with exemplary protection capabilities, rendering them suitable for deployment in both indoor and outdoor settings, including direct burial in soil. In scenarios where fire, smoke emission, and toxic fumes pose a significant risk to human life and equipment, the use of BS 6724 cables is a crucial safety measure.

Conductor:

Solid Aluminum or Copper conductor, round stranded or shaped, Class 2 to BS 6460, IEC 60228.

Insulation :

XLPE (Cross-Linked Polyethylene) Type GP 8 or ethylene propylene rubber (GP 6)

Colour Code :

1 Core : Brown

2 Cores: Brown,Blue

3 Cores: Brown, Black, Grey

4 Cores: Blue, Brown, Black, Grey

5 Cores: Green/Yellow, Blue, Brown, Black, Grey

Above 5 Cores: White Cores with black numbers

Bedding :LSOH (Low Smoke Zero Halogen)

Armour :

Single Core: AWA (Aluminum Wire Armour)

Multi Core: SWA (Steel Wire Armour)

Outer Sheath :LSOH (Low Smoke Zero Halogen)

Parameters of BS6724 Cable

Whats is BS6724 Cable

    BS 6724 represents the British Standard Specification for low-voltage armored cables with LSZH (Low Smoke Zero Halogen) insulation and sheath. The objective of these cables is to enhance fire safety and mitigate the emission of smoke in the event of a fire. The low-smoke, halogen-free materials utilized in the insulation and sheathing of the cable are meticulously formulated to minimize the release of toxic and corrosive gases when exposed to elevated temperatures, rendering them suitable for utilization in public areas, enclosed spaces, and densely populated areas.

BS 6724 armored low-smoke halogen-free cables are typically utilized in contexts where fire safety and reduced environmental impact are of paramount importance, including public buildings, transportation infrastructure, and areas with stringent safety regulations. The armoured construction provides mechanical protection, while the low-smoke halogen-free insulation and sheathing serve to enhance safety in the event of a fire.

In selecting and utilising BS 6724 armoured low smoke halogen-free cables, it is essential to consider the specific requirements of the installation, including compliance with pertinent standards, environmental implications and the necessity for fire-resistant and low smoke cables. Adherence to industry best practices and installation guidelines is essential for ensuring the appropriate and secure utilization of these cables in their designated applications.
