Application
The utilisation of rubber cables is associated with a number of advantages, which can be enumerated as follows:
The utilisation of rubber cables is associated with a number of advantages, which can be enumerated as follows:
The material exhibits robust resistance to wear. Rubber cables demonstrate excellent wear resistance, resilience to external physical damage, and suitability for deployment in challenging operational environments.
The cables demonstrate high-temperature resistance. Rubber cables are capable of functioning stably within a specified temperature range, exhibiting robust high-temperature resistance, and are suitable for deployment in high-temperature environments.
The cables demonstrate excellent flexibility. Rubber cables are flexible, allowing them to be easily bent and laid, making them suitable for use in situations that require bending or movement.
Oil resistance: Rubber cables exhibit good oil resistance, rendering them suitable for applications where corrosion by grease or chemical substances is a concern.
Weather resistance: Rubber cables demonstrate robust weather resistance, allowing for prolonged outdoor deployment without significant deterioration.
TECHNICAL DATA
Voltage: 450/750V
Tes t Voltage : 2500V
Flexing bending radius: 6 x Ø
Fixed bending radius: 4.0 x Ø
Fixed bending radius: 4.0 x Ø
Flexing Temperature: -25º C to +60º C
Fixed Temperature: -40º C to +60º C
Short circuit temperature: +200 º C
Flame retardant: IEC 60332.1
Insulation resistance: 20 MΩ x km
H07RN-F Single Core Type 450/750V EPR/PCP Trailing Rubber Cable
| Core and Size Mm sq | Stranding (Number of Strand/Strand Diameter | Thickness of Sheath mm | Nominal Overall Diameter mm | Approx. Weight kg/km |
| 2 X 1.0 | 32/0.20 | 0.8 | 8.4 | 95 |
| 2 X 1.5 | 30/0.50 | 0.8 | 9.4 | 115 |
| 2 X 2.5 | 50/0.25 | 0.9 | 11 | 165 |
| 2 X 4.0 | 56/0.30 | 1 | 12.8 | 235 |
| 2 X 6.0 | 84/0.30 | 1 | 14.2 | 295 |
| 2 X 10.0 | 80/0.40 | 1.2 | 20.4 | 575 |
| 2 X 16.0 | 126/0.40 | 1.2 | 23 | 775 |
| 2 X 25.0 | 196/0.40 | 1.4 | 27.4 | 1115 |
| 2 X 35.0 | 276/0.40 | 1.4 | 30.8 | 1475 |
| 3 X 1.0 | 32/0.20 | 0.8 | 9 | 109 |
| 3 X 1.5 | 30/0.50 | 0.8 | 10.3 | 143 |
| 3 X 2.5 | 50/0.25 | 0.9 | 11.8 | 204 |
| 3 X 4.0 | 56/0.30 | 1 | 13.7 | 286 |
| 3 X 6.0 | 84/0.30 | 1 | 15.2 | 377 |
| 3 X 10.0 | 80/0.40 | 1.2 | 21.9 | 715 |
| 3 X 16.0 | 126/0.40 | 1.2 | 24.7 | 976 |
| 3 X 25.0 | 196/0.40 | 1.4 | 29.4 | 1395 |
| 4 X 1.0 | 32/0.20 | 0.8 | 10 | 135 |
| 4 X 1.5 | 30/0.25 | 0.8 | 11.2 | 175 |
| 4 X 2.5 | 50/0.25 | 0.9 | 12.6 | 247 |
| 4 X 4.0 | 56/0.30 | 1 | 15.1 | 364 |
| 4 X 6.0 | 84/0.30 | 1 | 16.9 | 483 |
| 4 X 10.0 | 80/0.40 | 1.2 | 24 | 892 |
| 4 X 16.0 | 126/0.40 | 1.2 | 27 | 1226 |
| 4 X 25.0 | 196/0.40 | 1.4 | 32.6 | 1798 |
| 4 X 35.0 | 276/0.4 | 1.4 | 36.5 | 2385 |
| 4 X 50.0 | 396/0.4 | 1.6 | 42 | 3634 |
| 4 X 70.0 | 360/0.5 | 1.6 | 49 | 4833 |
| 4 X 95.0 | 475/0.5 | 1.8 | 55 | 6322 |
| 5 X 1.0 | 32/0.20 | 0.8 | 11 | 171 |
| 5 X 1.5 | 30/0.50 | 0.8 | 12.3 | 217 |
| 5 X 2.5 | 50/0.25 | 0.9 | 14.5 | 307 |
| 5 X 4.0 | 56/0.30 | 1 | 16.9 | 452 |
| 5 X 6.0 | 84/0.30 | 1 | 18.8 | 593 |
| 5 X 10.0 | 80/0.40 | 1.2 | 26.5 | 1110 |
| 5 X 16.0 | 126/0.40 | 1.2 | 30 | 1538 |
| 5 X 25.0 | 196/0.40 | 1.4 | 36 | 2210 |
| 5 X 35.0 | 276/0.40 | 1.4 | 40 | 2945 |
